Automatic HD satellite antenna

SMART is a feature that now makes it even easier for you to watch your favorite satellite programs.

You only need to press the ON-OFF button -on the intelligent control panel- and select a program on the satellite receiver or satellite television.

The antenna automatically raises and aligns itself to that satellite which is broadcasting the chosen television program.

If you change channels, the SMART system immediately checks which satellite is broadcasting the program and automatically re-aligns the antenna to that satellite within a few seconds.

The FlatSat Classic BT SMART is compatible with all satellite receivers and televisions (with built-in DVB-S2 satellite tuner) that support the DiSEqC function (such as Tivùsat, TNT Sat, Fransat, SKY, Canal Digitaal, TV Vlaanderen, Telesat etc.).

Operation and software updates

Via Teleco App (IOS or Android) the antenna / control unit can be controlled via bluetooth to adjust the desired satellite position. Software updates can also be performed this way, without the use of a PC or laptop, for example. This makes this antenna more user-friendly and easier to prepare for any (future) adjustments.

or directly request a customized quote for installing your dish on your camper or caravan.

With the new intelligent control panel it is possible to control the fully automatic satellite antenna with 'only' 2 buttons:

• With the ON-OFF button you can turn on the antenna and start the search function of the selected satellite or lower and turn off the antenna.
• The SAT button is used to select one of the 10 satellites that are in memory (Astra 19, Hot Bird, Astra 23, Astra 4, Eutelsat 5W, Astra 28, Thor, Hispasat, Turksat, Internet).
• The panel is equipped with a graphic OLED display to show everything done by the antenna and automatically turns off after a few seconds (when not in use).
• An anthracite-colored profile from the Berker line completes the control panel and can be easily replaced with other profiles in a different color that are simply commercially available.
• Safety system that allows the antenna to fold automatically when the vehicle is started.

The delivery of the TELECO Flatsat Classic BT Smart consists of:

• 1x external satellite antenna
• 1x control unit DVB-S2 (including cables)
• 1x intelligent control panel

Features of control unit DVB-S2 HD:

• Power supply: 12 - 24 Volts (10-31 Vdc)
• Max. consumption: 4 A
• Dimensions: 165 x 115 x 30 mm
• Weight: 0.250 kg

Deliverable models of the TELECO Flatsat Classic BT Smart fully automatic satellite dish:

Deliverable models		Diameter dish
FLATSAT CLASSIC BT SMART 65		63.5 x 69 cm
FLATS CLASSIC BT SMART 85		85 x 78 cm
Optional:	Twin LNB - The Teleco Twin LNB allows you to connect two receivers to your Teleco satellite antenna through two coaxial outputs. So you can provide two receivers with radio and TV signals.

Footprint

Footprint tips for choosing the right dish

Within the colored areas (Foot Prints), reception of television and radio signals indicated by the 5 indicated satellite groups is guaranteed. You should keep in mind that in case of cloudy weather and rain, the signals become weaker and it may therefore happen in such cases that you receive images with macro blocks or the images may even disappear. It is therefore important that you carefully consider the choice of satellite system to be installed on your vehicle and include in it whether the dimensions of the satellite dish are suitable to receive the satellite signals properly at the place where you want to spend your vacations.
