Product description
This cable is supplied without connectors!
The 5D-FB signal booster antenna cable is a high-quality coaxial cable designed for applications where reliability, low attenuation, and maximum signal stability are essential. Thanks to its minimal signal loss and excellent shielding, this cable is ideal for RF installations, Wi-Fi antennas, telecom systems, ham radio, 4G/5G antennas, and professional communication networks.
The 5D-FB cable is known for its low attenuation over long distances, robust construction, and consistent performance, even in demanding conditions. With this cable, you’re guaranteed a strong, stable, and interference-free signal.
Please note: using a cable that is too long for the signal amplifier will result in signal loss. This normally occurs at a rate of 0.2% loss per metre. We therefore recommend that you do not use cables longer than 30 metres for outdoor signals below 60%.
Main features 5D-FB signal booster antenna cable
Technical Performance
✔️ Very low signal attenuation for optimal transmission
✔️ Suitable for GSM 800 & 900MHz, CDMA, DCS, PCS, 3G and WCDMA
✔️ High shielding against interference (RFI/EMI)
✔️ The operating frequency of the cable is 0-3 GHz and is suitable for use in combination with all HiBoost signal amplifiers
(or other models)
Construction & Quality
✔️ Premium 5D-FB coaxial structure
✔️ Durable outer jacket for indoor and outdoor use
✔️ Flexible yet sturdy design for easy installation
Applications
✔️ Ideal for amplifier and antenna installations
✔️ Suitable for long-term professional infrastructure
Technical parameters 5D-FB signal booster antenna cable
| Project | Material | Diameter (mm) |
| Inner conductor | Solid Copper or Copper Clad Aluminum | 1.80 |
| Dielectric | Physical Foam Polyethylene | 5.00 |
| First shield | Bonded Aluminum/Polyester/Aluminum tape | 5.20 |
| Outer conductor | Tinned Copper Braid | 5.70 |
| Jacket | Black PVC or Polyethylene | 7.50 |
Electrical & Mechanical Parameters
| Electrical Parameters | Mechanical Parameters |
| Capacitance (Pf/M) | 82 |
| Impedance (ohm) | 50 |
| Velocity (%) | 82 |
| Inner Conductor DC Resistance (Ω/KM) | 6.8/10.5 |
| Outer Conductor DC Resistance (Ω/KM) | 14.1 |
| Shielded attenuation（dB） | >80 |
Mechanical & Environment Parameters
| Storage temperature (℃) | -25 to +70 |
| Installation temperature (℃) | -25 to +70 |
| Working temperature (℃) | – 25 to +70 |
| Minimum bend radius (mm) | 27 |
| VSWR | |
| 5-3000MHz | ≤1.20 |
| Attenuation (20℃) | |
| Frequency (MHz) | Attenuation (dB/100m) |
| 150 | 7.80 |
| 280 | 10.80 |
| 350 | 12.10 |
| 400 | 13.00 |
| 900 | 20.20 |
| 1200 | 23.70 |
| 1500 | 26.80 |
| 1800 | 29.70 |
| 2200 | 33.30 |
| 2500 | 35.80 |
| SKU | 5D-FB |
|---|---|
| Stock Notice | Delivery Time ca. 2 - 5 Days |
| Accessories | Cable |
-
