Maxview Roam X - mobile 4G WiFi solution

The Internet connection available during your vacation or trip across Europe can often be disappointing. Many times the 4G/5G signal on your smartphone is weak or even non-existent, especially if you are in a remote location. Even the WiFi connection available at the campsite or port often leaves much to be desired and shared with many. The result is a poor and slow Internet connection, which often makes surfing the Internet or streaming a TV program hardly or not possible.

The Maxview Roam X solution uses a powerful external, roof-mounted antenna and an internal router. The solution is a reliable and secure WiFi hotspot for your RV, caravan, boat, yacht or ship. The Maxview solution is unique in that the Roam X helps you get better Internet in two ways.

• 4G/5G signal - the main purpose of the Roam X is to use a 4G/5G signal to get a WiFi connection; this is the Maxview Roam X's most powerful and fastest solution. With the 4G/5G LTE antenna, the signal is so strong that you can have an Internet connection where your smartphone, for example, cannot manage it.
• WiFi hotspot - in addition, the Maxview Roam X can also be used to connect to a usable WiFi hotspot. This solution uses the powerful internal antenna on the Maxview Roam X Router. Data usage on your SIM card can be minimized this way, provided a reliable WiFi source is available.

Maxview Roam X - antenna

A powerful omni-directional LTE antenna, with unique features, and a strong router designed to provide a fast and stable Internet connection during your trip around Europe. Suitable for use on both land and (inland) water.

Powerful 4G LTE antenna; the Maxview Roam X is a powerful LTE rooftop antenna designed specifically for use in your RV, caravan, truck, yacht, boat or ship, and optimized for use in rural, water and remote locations. Sleek antenna design; low profile and streamlined design for roof mounting. The antenna takes up minimal space and can be mounted in almost any position. Different mounting options optionally available. Suitable for travel within Europe; the Maxview Roam X is -depending on your data provider- optimized to work throughout Europe. Static and mobile connectivity; offers both connectivity while traveling or when stationary. Omni-directional; Because the LTE antenna receives signals over 360 degrees, there is no need to manually adjust the Roam X antenna in terms of direction. Reliable data transmission; 1.5-meter cable with (SMA) connectors for reliable data transmission is included. Easy installation; the self-adhesive pad and clamp allow for quick and easy installation on the roof of your RV or caravan or aboard your boat, ship or yacht. Once the antenna is installed, the rest is Plug & Play in terms of installation and commissioning.

Maxview Roam X - Plug & Play router

A 4G/5G solution is generally the fastest and most stable Internet connection, but in some cases a WiFi hotspot can be convenient. When this is the case, you do not need to use up your 4G/5G data and can switch to a WiFi hotspot.

The Maxview Roam X offers the best of both worlds; when available, a WiFi connection can be used to minimize data usage.

4G(LTE) - CAT6 download up to 300 Mbps, upload up to 50 Mbps Frequency/amplification 802.11.b/g/n/ac - 2.4GHz - 5GHz MU-MIMO for faster speeds on multiple devices 2 WiFi antennas for more coverage Dual SIM slots Connectivity of up to 100 devices (tablets, smartphones, laptops, SmartTVs, etc.)

SIM card

.The Maxview Roam X solution is designed so that it can be combined with (almost) any data provider; this makes it possible to use the network that is most suitable for you! So even your current provider can be used, based on your existing SIM card. It often pays off -when planning a trip- to include national or European coverage in the comparison in addition to price and usage.

If you plan to go to Scotland, for example, EE's coverage is often considered superior, while Vodafone and T-mobile are again more popular if you are traveling within mainland Europe.

Check the limitations of your network provider and data SIM therefore; especially when traveling abroad, we believe you should pay attention to factors such as: the number of days abroad, usage and limitations of roaming partners. We recommend having a spare SIM card with you while abroad that does not expire if not used. Then you will always have a backup with you!

How much data does what consume?

This table summarizes the data usage of the mentioned activities.

These values are for guidance only and depend on many factors such as download quality, devices, networks and download speed.

Installation options Maxview Roam X 4G/5G WiFi antenna (optionally available)

Standard installation	Roof mount MXL050 / KIT1 (optionally available)	Compensation connection (not yet available)

Technical data Maxview Roam 4G/5G WiFi antenna + router

Maxview Roam X - router	Maxview Roam X - antenna
Router type: 4G LTE and WiFi Speed: up to 300 Mbps Connectors: 2x SMA Ethernet ports: 4x RJ- 45 (WAN and LAN Voltage: 9-30V (reverse polarity protection) Connector with switch and 2A fuse Current consumption: 0.4A Web page locking: Yes Max. connect: Up to 100 External antenna: 1x 3G/4G (for external rooftop antenna) 2x Wifi for internal rod antenna Dimensions: 270 x 115 x 45 mm Weight: 550g	Type: Omnidirectional antenna MU-MIMO Frequency: 698 - 6.000 MHz / 5.9dBi- 8.8dBi Boost: 5.9dBi - 8.8dBi Wi-Fi: MU-MIMO - 802.11.b/g/n/ac - 2.4 GHz - 5 GHz Connection type: 2x SMA Compatible speeds: up to 300Mps Impedance: 50 Ohms Voltage: 9-30 VDC (reverse polarity protection) Cable length: 1.5m Casing: Aluminum base plate, UV stable ASA housing Dimensions: 196 x 65 mm Fixing material: central hollow screw

Maxview Roam vs. Maxview Roam X - 4G/5G WiFi solution
