World-wide view - the Intellian® i9P offers even more comprehensive coverage of satellite TV reception, making it the ideal solution for larger yachts, ships and commercial vessels traveling across global regions. With its highly accurate satellite tracking capability, the i9 outperforms in all conditions.

Intellian® i9 highlights

• The i9P features Auto Skew giving you even better fine tuning of the LNB for the best signal reception wherever you are
• Automatic satellite selection function via remote control
• Compatible with leading satellite TV providers around the world
• The rotation speed of 30° per second allows for signal tracking at both high speeds and in rough seas
• An extended elevation range of -15° to 90° allows you to travel far north or south
• Built-in GPS system allows for quick signal finding
• Simplicity of design, no external compass or speed sensors required
• Built-in HD module for Ku-band HD TV reception

The Intellian® i9P is known for its professional build, ruggedness and excellent signal reception. This makes the i9P the ideal solution for ocean cruisers, larger yachts, commercial vessels and oil rigs. And if the i9P is equipped with Intellian's proprietary WorldView LNB then there is global signal reception, without manual intervention. Make your crew feel at home with the Intellian i9P!

Automatic satellite switching

DISH Network (US) and Bell TV (Canada) users will benefit from using the Intellian MIM (Multi-Satellite Interface Module). The Intellian MIM is needed to enable automatic switching between satellites, which also allows water sports users who want to switch channels to automatically switch to the correct satellite, just like satellite TV at home.

Intellian® i9P features

Fully automatic system

• Automatic satellite  search and identification function
• The 2-axis stabilization ensures fast finding of the correct satellite/signal strength

High Performance dish antenna

• The parabolic dish has a diameter of 85cm (34inch) and is suitable for the reception of Ku-band satellite signals
• Built-in HD module for Ku-band HD TV reception

Intellian's patented Quick & Quiet℠ Technology (IQ²)

• With the patented IQ² Technology, quick tuning to the desired satellite is possible and this technology ensures a solid signal quality while watching your favorite TV programs. Even while sailing!
• The Wide Range Search (WRS) algorithm ensures fast finding of the best signal strength available -wherever
• Dynamic Beam Tilting (DBT) technology uses intelligent, real-time beam analysis to ensure a ​​superior signal quality, while this technology eliminates intrusive background noise -that one may experience with conventional satellite dishes

Control Unit

• Intuitive controls with digital information display on the ACU
• Wireless automatic updates and diagnostics via Aptus PC and Aptus Mobile
• DC Out port for easy power supply to the Intellian MIM or Shaw Decoder Module

Multiple connections possible

Multiple satellite receivers and/or televisions can be connected to the Intellian i9P using a multi-switch or the Intellian MIM system (Multi-Satellite Interface Module). Through the MIM, a master receiver can be selected to receive the desired satellite.

In North America, when using Dish Network or Bell TV, an MIM is required; this allows automatic satellite switching through your remote control, just like in your home.

Built-in GPS and NMEA 0183 Interface

• The Intellian® i9P features a built-in GPS antenna for quick alignment to the correct satellite / best signal strength.
• The vessel's GPS system can also be connected via the NMEA 0183 port on the ACU's rear panel.

Compact size

The Intellian® i9P has an all around diameter of 113cm (44.5 inches) and weighs 55.0 kg (212 lbs).

Three-Year Global Warranty

Leading parts with a 3-year warranty and craftsmanship with a 1-year warranty on all Intellian® satellite antenna systems, give you peace of mind and a good feeling with your hardware investment.

Content delivery

• Antenna & Radome 85 cm (34 inch) Reflector & LNB
• ACU (Antenna Control Unit)
• PC Controller Program (software CD included)
• Installation and Operation Manual
• Installation Template
• Quick Installation Guide

Installation Kit

• ACU Table Mounting Bracket × 2EA
• 15 m (49 ft) × 1EA Antenna-ACU RG6 coaxial cable
• 3 m (10 ft) × 1EA ACU-IRD RG6 coaxial cable
• 10 m (33 ft) × 1EA DC power cable
• 1.8 m (6 ft) × 1EA PC serial cable
• Connectors & screws

strong>Comparison chart Intellian® i9, i6, i4 and i3 model

		SatFlower i9	SatFlower i6P	SatFlower i4	SatFlower i3
Diameter antenna	85cm	60cm	45cm	37cm
Dimensions	122 x 113cm	70 x 72cm	50 x 53cm	43 x 44cm
Weight	56.2kg	18kg	14kg	9kg
Minimum EIRP	44dBw	47dBw	49dBw	50dBw
Suitable for	North America, Europe, Central America, South America, Asia, Africa, Middle East, Oceania	Europe, Central America, South America, Asia, Africa, Middle East, Oceania	North America, Europe, Central America, South America, Asia, Africa, Middle East, Oceania	North America, Europe, Central America, South America, Asia, Africa, Middle East, Oceania
Antenna Control Unit	Yes	Yes	Yes	Yes
Automatic SKEW	Yes	Yes	No	No
HDTV compatible	Yes	Yes	Yes	Yes
GPS integrated	Yes	Yes	No	No
GPS interface	Yes	Yes	Yes	Yes
