Product description
Please note: Each EVERY Peli Case is put together based on your order/specific requirements; therefore, for this reason, the delivery time of the EVERY Peli Case may vary in terms of duration.
The EVERY PELI Case solution, designed specifically for the Iridium Certus 700 satellite service, enables global communications coverage regardless of landscape, weather conditions (IP-64) and power availability.
All EVERY PELI Case solutions operate fully when the lid is closed (no manual aiming required) and operate fully autonomously via the included batteries for up to 12 hours (depending on the satellite terminal and data usage).
The EVERY MissionLINK carrying case offers the most advanced features for extreme and truly portable mobile satellite communications solutions.
| LTE option (optional) The EVERY - LTE option provides wireless LTE connectivity as a priority link and has an automatic failover to satellite service when the LTE connection is lost or unavailable. Proven world-class LTE gateways from Sierra Wireless (AirLink® LX60) are used for commercial & business LTE network connectivity. The AirLink LX60 is fully licensed for North America, EMEA or Australia & New Zealand. |  |
| DRIVE option (optional) With the DRIVE option, the satellite terminal antenna can be removed from the housing without tools to be mounted on the roof of a vehicle using magnetic feet. This allows full connection to the satellite network while driving. All antennas can be used inside or outside the PELI Case while the lid is closed. |  |
Smart Batteries
|  |
Waterproof
|  |
Hot-Swap function
|  |
Colors
|  |
Flightable
|  |
IP-67 Interfaces
|  |
.
Technical specifications EVERY MissionLINK 700 satellite communications kit
| Weight | 20.0 Kg | |
| Dimensions | 61.4 x 46.5 x 30.7 cm | |
| Environmental factors | Dust and water | IP-64 protection class |
| Temperature | -30°C to +55°C in operation -22°F to +131°F in operation | |
| Interfaces | - Dual band 802.11ac Wi-Fi hot-spot - 2x External ethernet port ́s (RJ-45) - 1x External phone port (RJ-45) | |
| Nutrition | External power supply | Input voltage 90 - 264V AC, Output voltage 16.8V DC (84W) |
| Vehicle | Input voltage 12V DC | |
| Battery | 2x removable batteries (98 Wh/ 6.8 Ah); External 2-channel battery charger (90 - 264 V AC) options | |
| Communications | Thales MissionLINK | - up to 700 kbps (down) - tto 352 kbps (up) - 256 kbps (streaming) |
| Other features | Commercial and business LTE network< brbr> LX60 fully licensed versions for North America, EMEA and Australia & New Zealand are available Fully autonomous tracking antenna receives and tracks BGAN satellite signal en route or during standstill Victron Energy Smart BatteryProtect |
|
| DRIVE Option | Change the following interfaces: | + 1x TNC port (external) |
| Change the following components: | + Antenna socket with cable entry (Antenna is no longer mounted stationary in the housing) | |
| LTE Option | Change the following interfaces: | - 1x sat only RJ-45 ethernet port + 1x LTE with sat failover RJ-45 ethernet port |
| Change the following components: | - Wi-Fi antenna + AirLink LX60 LTE router + SharkFin 4in1 antenna (LTE, diversity, Wi-Fi & GPS) | |
| Delivery contents | EVERY MissionLINK | - PELI Case 1560 - Thales MissionLINK - High gain Wi-Fi antenna - BatteryProtect (integrated) - External charger (incl. travel case) - 3m vehicle cable - 3m ethernet cable - 2 x 98Wh/ 6.8Ah batteries (incl. travel case) - Quick start guide |
| SKU | EVERY 700 |
|---|---|
| Stock Notice | Delivery Time ca. 14 Days |
| Brand | Iridium |
-
